Cabana_Grid_ParticleInit.hpp File Reference

Particle creation utilities based on uniform grids. More...

#include <Cabana_Grid_Parallel.hpp>
#include <Cabana_Grid_ParticleList.hpp>
#include <Cabana_ParticleInit.hpp>
#include <Cabana_Slice.hpp>
#include <Kokkos_Core.hpp>
#include <Kokkos_Random.hpp>
#include <exception>

Include dependency graph for Cabana_Grid_ParticleInit.hpp:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Namespaces
namespace	Cabana
	Core: particle data structures and algorithms.

Functions
template<class ExecutionSpace, class InitFunctor, class ParticleListType, class LocalGridType>
int	Cabana::Grid::createParticles (Cabana::InitRandom, const ExecutionSpace &exec_space, const InitFunctor &create_functor, ParticleListType &particle_list, const int particles_per_cell, LocalGridType &local_grid, const std::size_t previous_num_particles=0, const bool shrink_to_fit=true, const uint64_t seed=123456, typename std::enable_if< is_particle_list< ParticleListType >::value, int >::type *=0)
	Initialize a random number of particles in each cell given an initialization functor.
template<class InitFunctor, class ParticleListType, class LocalGridType>
int	Cabana::Grid::createParticles (Cabana::InitRandom tag, const InitFunctor &create_functor, ParticleListType &particle_list, const int particles_per_cell, LocalGridType &local_grid, const std::size_t previous_num_particles=0, const bool shrink_to_fit=true, const uint64_t seed=123456, typename std::enable_if< is_particle_list< ParticleListType >::value, int >::type *=0)
	Initialize random particles per cell given an initialization functor.
template<class ExecutionSpace, class PositionType, class LocalGridType>
void	Cabana::Grid::createParticles (Cabana::InitRandom, const ExecutionSpace &exec_space, PositionType &positions, const int particles_per_cell, LocalGridType &local_grid, const std::size_t previous_num_particles=0, const uint64_t seed=123456, typename std::enable_if<(Cabana::is_slice< PositionType >::value||Kokkos::is_view< PositionType >::value), int >::type *=0)
	Initialize a random number of particles in each cell.
template<class PositionType, class LocalGridType>
void	Cabana::Grid::createParticles (Cabana::InitRandom tag, PositionType &positions, const int particles_per_cell, LocalGridType &local_grid, const std::size_t previous_num_particles=0, const uint64_t seed=123456, typename std::enable_if<(Cabana::is_slice< PositionType >::value||Kokkos::is_view< PositionType >::value), int >::type *=0)
	Initialize a random number of particles in each cell.
template<class ExecutionSpace, class InitFunctor, class ParticleListType, class LocalGridType>
int	Cabana::Grid::createParticles (Cabana::InitUniform, const ExecutionSpace &exec_space, const InitFunctor &create_functor, ParticleListType &particle_list, const int particles_per_cell_dim, LocalGridType &local_grid, const std::size_t previous_num_particles=0, const bool shrink_to_fit=true, typename std::enable_if< is_particle_list< ParticleListType >::value, int >::type *=0)
	Initialize uniform particles per cell given an initialization functor.
template<class InitFunctor, class ParticleListType, class LocalGridType>
int	Cabana::Grid::createParticles (Cabana::InitUniform tag, const InitFunctor &create_functor, ParticleListType &particle_list, const int particles_per_cell_dim, LocalGridType &local_grid, const std::size_t previous_num_particles=0, const bool shrink_to_fit=true, typename std::enable_if< is_particle_list< ParticleListType >::value, int >::type *=0)
	Initialize uniform particles per cell given an initialization functor.
template<class ExecutionSpace, class PositionType, class LocalGridType>
void	Cabana::Grid::createParticles (Cabana::InitUniform, const ExecutionSpace &exec_space, PositionType &positions, const int particles_per_cell_dim, LocalGridType &local_grid, const std::size_t previous_num_particles=0, typename std::enable_if<(Cabana::is_slice< PositionType >::value||Kokkos::is_view< PositionType >::value), int >::type *=0)
	Initialize a uniform number of particles in each cell.
template<class PositionType, class LocalGridType>
void	Cabana::Grid::createParticles (Cabana::InitUniform tag, PositionType &positions, const int particles_per_cell_dim, LocalGridType &local_grid, const std::size_t previous_num_particles=0, typename std::enable_if<(Cabana::is_slice< PositionType >::value||Kokkos::is_view< PositionType >::value), int >::type *=0)
	Initialize a uniform number of particles in each cell.

Detailed Description

Particle creation utilities based on uniform grids.

Function Documentation

createParticles() [1/8]

template<class InitFunctor, class ParticleListType, class LocalGridType>

int Cabana::Grid::createParticles	(	Cabana::InitRandom	tag,
		const InitFunctor &	create_functor,
		ParticleListType &	particle_list,
		const int	particles_per_cell,
		LocalGridType &	local_grid,
		const std::size_t	previous_num_particles = 0,
		const bool	shrink_to_fit = true,
		const uint64_t	seed = 123456,
		typename std::enable_if< is_particle_list< ParticleListType >::value, int >::type *	= 0 )

Initialize random particles per cell given an initialization functor.

Parameters

tag	Initialization type tag.
create_functor	A functor which populates a particle given the logical position of a particle. This functor returns true if a particle was created and false if it was not giving the signature: bool createFunctor( const double pid, const double px[3], const double pv, typename ParticleAoSoA::tuple_type& particle );
particle_list	The ParticleList to populate. This will be filled with particles and resized to a size equal to the number of particles created.
particles_per_cell	The number of particles to sample each cell with.
local_grid	The LocalGrid over which particles will be created.
previous_num_particles	Optionally specify how many particles are already in the container (and should be unchanged).
shrink_to_fit	Optionally remove unused allocated space after creation.
seed	Optional random seed for generating particles.

createParticles() [2/8]

template<class PositionType, class LocalGridType>

void Cabana::Grid::createParticles	(	Cabana::InitRandom	tag,
		PositionType &	positions,
		const int	particles_per_cell,
		LocalGridType &	local_grid,
		const std::size_t	previous_num_particles = 0,
		const uint64_t	seed = 123456,
		typename std::enable_if<(Cabana::is_slice< PositionType >::value||Kokkos::is_view< PositionType >::value), int >::type *	= 0 )

Initialize a random number of particles in each cell.

Parameters

tag	Initialization type tag.
positions	Particle positions slice. This should be already the size of the number of grid cells times particles_per_cell.s
particles_per_cell	The number of particles to sample each cell with.
local_grid	The LocalGrid over which particles will be created.
previous_num_particles	Optionally specify how many particles are already in the container (and should be unchanged).
seed	Optional random seed for generating particles.

createParticles() [3/8]

template<class ExecutionSpace, class InitFunctor, class ParticleListType, class LocalGridType>

int Cabana::Grid::createParticles	(	Cabana::InitRandom	,
		const ExecutionSpace &	exec_space,
		const InitFunctor &	create_functor,
		ParticleListType &	particle_list,
		const int	particles_per_cell,
		LocalGridType &	local_grid,
		const std::size_t	previous_num_particles = 0,
		const bool	shrink_to_fit = true,
		const uint64_t	seed = 123456,
		typename std::enable_if< is_particle_list< ParticleListType >::value, int >::type *	= 0 )

Initialize a random number of particles in each cell given an initialization functor.

Parameters

exec_space	Kokkos execution space.
create_functor	A functor which populates a particle given the logical position of a particle. This functor returns true if a particle was created and false if it was not giving the signature: bool createFunctor( const double pid, const double px[3], const double pv, typename ParticleAoSoA::tuple_type& particle );
particle_list	The ParticleList to populate. This will be filled with particles and resized to a size equal to the number of particles created.
particles_per_cell	The number of particles to sample each cell with.
local_grid	The LocalGrid over which particles will be created.
previous_num_particles	Optionally specify how many particles are already in the container (and should be unchanged).
shrink_to_fit	Optionally remove unused allocated space after creation.
seed	Optional random seed for generating particles.

createParticles() [4/8]

template<class ExecutionSpace, class PositionType, class LocalGridType>

void Cabana::Grid::createParticles	(	Cabana::InitRandom	,
		const ExecutionSpace &	exec_space,
		PositionType &	positions,
		const int	particles_per_cell,
		LocalGridType &	local_grid,
		const std::size_t	previous_num_particles = 0,
		const uint64_t	seed = 123456,
		typename std::enable_if<(Cabana::is_slice< PositionType >::value||Kokkos::is_view< PositionType >::value), int >::type *	= 0 )

Initialize a random number of particles in each cell.

Parameters

exec_space	Kokkos execution space.
positions	Particle positions slice. This should be already the size of the number of grid cells times particles_per_cell.s
particles_per_cell	The number of particles to sample each cell with.
local_grid	The LocalGrid over which particles will be created.
previous_num_particles	Optionally specify how many particles are already in the container (and should be unchanged).
seed	Optional random seed for generating particles.

createParticles() [5/8]

template<class InitFunctor, class ParticleListType, class LocalGridType>

int Cabana::Grid::createParticles	(	Cabana::InitUniform	tag,
		const InitFunctor &	create_functor,
		ParticleListType &	particle_list,
		const int	particles_per_cell_dim,
		LocalGridType &	local_grid,
		const std::size_t	previous_num_particles = 0,
		const bool	shrink_to_fit = true,
		typename std::enable_if< is_particle_list< ParticleListType >::value, int >::type *	= 0 )

Initialize uniform particles per cell given an initialization functor.

Parameters

tag	Initialization type tag.
create_functor	A functor which populates a particle given the logical position of a particle. This functor returns true if a particle was created and false if it was not giving the signature: bool createFunctor( const double pid, const double px[3], const double pv, typename ParticleAoSoA::tuple_type& particle );
particle_list	The ParticleList to populate. This will be filled with particles and resized to a size equal to the number of particles created.
particles_per_cell_dim	The number of particles to populate each cell dimension with.
local_grid	The LocalGrid over which particles will be created.
previous_num_particles	Optionally specify how many particles are already in the container (and should be unchanged).
shrink_to_fit	Optionally remove unused allocated space after creation.

createParticles() [6/8]

template<class PositionType, class LocalGridType>

void Cabana::Grid::createParticles	(	Cabana::InitUniform	tag,
		PositionType &	positions,
		const int	particles_per_cell_dim,
		LocalGridType &	local_grid,
		const std::size_t	previous_num_particles = 0,
		typename std::enable_if<(Cabana::is_slice< PositionType >::value||Kokkos::is_view< PositionType >::value), int >::type *	= 0 )

Initialize a uniform number of particles in each cell.

Parameters

tag	Initialization type tag.
positions	Particle positions slice. This should be already the size of the number of grid cells times particles_per_cell.s
particles_per_cell_dim	The number of particles to populate each cell dimension with.
local_grid	The LocalGrid over which particles will be created.
previous_num_particles	Optionally specify how many particles are already in the container (and should be unchanged).

createParticles() [7/8]

template<class ExecutionSpace, class InitFunctor, class ParticleListType, class LocalGridType>

int Cabana::Grid::createParticles	(	Cabana::InitUniform	,
		const ExecutionSpace &	exec_space,
		const InitFunctor &	create_functor,
		ParticleListType &	particle_list,
		const int	particles_per_cell_dim,
		LocalGridType &	local_grid,
		const std::size_t	previous_num_particles = 0,
		const bool	shrink_to_fit = true,
		typename std::enable_if< is_particle_list< ParticleListType >::value, int >::type *	= 0 )

Initialize uniform particles per cell given an initialization functor.

Parameters

exec_space	Kokkos execution space.
create_functor	A functor which populates a particle given the logical position of a particle. This functor returns true if a particle was created and false if it was not giving the signature: bool createFunctor( const double px[3], typename ParticleAoSoA::tuple_type& particle );
particle_list	The ParticleList to populate. This will be filled with particles and resized to a size equal to the number of particles created.
particles_per_cell_dim	The number of particles to populate each cell dimension with.
local_grid	The LocalGrid over which particles will be created.
previous_num_particles	Optionally specify how many particles are already in the container (and should be unchanged).
shrink_to_fit	Optionally remove unused allocated space after creation.

createParticles() [8/8]

template<class ExecutionSpace, class PositionType, class LocalGridType>

void Cabana::Grid::createParticles	(	Cabana::InitUniform	,
		const ExecutionSpace &	exec_space,
		PositionType &	positions,
		const int	particles_per_cell_dim,
		LocalGridType &	local_grid,
		const std::size_t	previous_num_particles = 0,
		typename std::enable_if<(Cabana::is_slice< PositionType >::value||Kokkos::is_view< PositionType >::value), int >::type *	= 0 )

Initialize a uniform number of particles in each cell.

Parameters

exec_space	Kokkos execution space.
positions	Particle positions slice. This should be already the size of the number of grid cells times particles_per_cell.s
particles_per_cell_dim	The number of particles to populate each cell dimension with.
local_grid	The LocalGrid over which particles will be created.
previous_num_particles	Optionally specify how many particles are already in the container (and should be unchanged).
